Automatic High Speed Folder Gluer HR-1100FC II

Automatic high-speed box gluer and folding machine-adopts modular design, which can meet different needs of customers; installation and operation are simple, and the structure design is more effective to solve the production of special-shaped boxes. The transmission mode of the whole machine adopts hexagonal shaft and multi-ribbed belt transmission, which is efficient and energy-saving, quiet and stable. The upper and lower dual power structure ensures smooth paper feeding and accurate folding l

    Technical specifications

    型号/Model

    HR-650FC II

    HR-800FC IIHR-1100FC II
    适用纸型/Suitable Material

    卡纸200g~900/m2&N,F,E浪美妆瓦椤纸

    Cardboard 200~900g/m2 & N,F,E-Flute corrugated paper

    胶水类型/Type of Adhesive溶剂型  Resin emulsion (solvent)
    折返方式/Way of Pre-fold第一折线180度,第三折线135度 First folding line 180 degree,and the third folding line 135 degree
    最快速度/Max. Speed300 m/min
    所需电力/Required Power9kw9kw17KW
    机械尺寸/Machine Dimension12200mm*1520mm*1460mm12200mm*1650mm*1460mm14000mm*2100mm*1500mm
    机械重量/Machine Weight5320kg5650kg11760kg


    Optional configuration

    ●  四、六角贴装置

    ●  自动冷、热喷胶系统

    ●  等离子处理器

    ●  胶水检测系统

    ●  条码检测

    ●  自动剔除装置

    ●  4/6 corner devices

    ●  Automatic cold & hot glue system

    ●  Plasma treatment system

    ●  Glue detection system

    ●  Bar code reader

    ●  Automatic rejector device


  • Parameters

    Technical specifications

    型号/Model

    HR-650FC II

    HR-800FC IIHR-1100FC II
    适用纸型/Suitable Material

    卡纸200g~900/m2&N,F,E浪美妆瓦椤纸

    Cardboard 200~900g/m2 & N,F,E-Flute corrugated paper

    胶水类型/Type of Adhesive溶剂型  Resin emulsion (solvent)
    折返方式/Way of Pre-fold第一折线180度,第三折线135度 First folding line 180 degree,and the third folding line 135 degree
    最快速度/Max. Speed300 m/min
    所需电力/Required Power9kw9kw17KW
    机械尺寸/Machine Dimension12200mm*1520mm*1460mm12200mm*1650mm*1460mm14000mm*2100mm*1500mm
    机械重量/Machine Weight5320kg5650kg11760kg


    Optional configuration

    ●  四、六角贴装置

    ●  自动冷、热喷胶系统

    ●  等离子处理器

    ●  胶水检测系统

    ●  条码检测

    ●  自动剔除装置

    ●  4/6 corner devices

    ●  Automatic cold & hot glue system

    ●  Plasma treatment system

    ●  Glue detection system

    ●  Bar code reader

    ●  Automatic rejector device


自动高速糊折盒机给纸部Paper Supply Department
Independent transmission design, accurate paper transfer and adjustable to ensure the highest productivity. The paper feed knife and the left and right fixed rods are designed pneumatically up and down, which is easy and convenient. Multiple high-quality thick belts, combined with an electric paper stacking vibration device, ensure accurate and smooth paper conveying; the adjustment of the various mechanisms of the paper feeding part is convenient and easy, and the time for calibration and change is shortened.

Turn-back department
For the first line (that is, the glue tongue), make a 180-degree turn back and the third line for a 135-degree turn, which is suitable for the unfolding of the product that needs to enter the automatic packaging line when filling the real object. And can provide folding auxiliary functions for products that need to be folded multiple times.



Lock bottom

The modular bottom hook assembly can accurately complete the bottom hook work of the bottom locking product, and it is flexible and convenient to disassemble and assemble.


Glue department

Equipped with two groups of left and right glue cylinders, upper and lower glue cylinders, which can fine-tune the amount of glue individually and accurately; it is easy to disassemble and assemble, and is easy to clean and maintain.


Honoribe

Lengthen the stroke, so that the cardboard can be fully stretched here, and then take shape. The upper pressing rod is movable, which is convenient for making special box-shaped workstations. The intermediate conveyor is designed to move up and down. When producing smaller boxes, there is no need to disassemble and assemble parts, and the operation is labor-saving.


Pressure Transmission Department

The slider-type adjustment mechanism is flexible and convenient to ensure the natural and smooth accumulation of cartons of different sizes in this part. It is equipped with electronic induction counting and production capacity prediction, spraying and kicking counting settings, which can be automatically tracked.


Transport Department

Two high-quality imported belts are soft and moderate; pneumatic pressure increase and decrease can be used for fine fine-tuning control to ensure the perfect compression effect of the product in this part.

Foundation plan

Automatic High Speed Folder Gluer HR-1100FC II
Automatic high-speed box gluer and folding machine-adopts modular design, which can meet different needs of customers; installation and operation are simple, and the structure design is more effective to solve the production of special-shaped boxes. The transmission mode of the whole machine adopts hexagonal shaft and multi-ribbed belt transmission, which is efficient and energy-saving, quiet and stable. The upper and lower dual power structure ensures smooth paper feeding and accurate folding l
