HR-800GL

Automatic High Speed PVC/PET/PP Folder Gluer



  1. Home
  2. >
  3. 800 Automatic High Speed PVC_PET_PP Folder Gluer and Folding Machine
自动高速PVC/PET/PP 糊折盒机

Component

组成部份
Paper feeding department
Paper feeding department
Pre-folding
Pre-folding
Hook bottom
Hook bottom
Honoribe
Honoribe
Laminating Department
Laminating Department
Pressure Transmission Department
Pressure Transmission Department
Transport Department
Transport Department

Production box type

图片展示

Technical specifications

图片展示

Production box type

图片展示

Technical specifications

图片展示

Production Box Type

One-side gluing

   Bottom gluing


Applicable Material

PVC、PET、PP Plastic sheet


Technical Parameters

Model: HR-800GL

Suitable material

PVC,PET,PP Plastic

Width of the sheet

50mm-800mm

Thickness of the film

0.1mm-0.8mm

Max. speed

260m/min

Total power

13.5kw

Overall dimension(L*W*H)

15000mm*1450mm*1450mm
Net weight5.6T

BENEFITS AND FEATURES

Feeding Unit

● Independent transmission design, accurate feeding is adjustable, to ensure maximum production capacity. Feeding knife and left & right positioning levers are pneumatic vertical design, easy and convenient.

Pre-folding Unit

● Independent pre-folding section, for making small size boxes, box in box type products etc.

Crash Lock Bottom Unit

● Modular crash lock bottom components finish the crash lock bottom job accurately, dismantling is flexible and convenient.

Final Folding Unit

● Extended long journey design makes the product stretches fully in this sector and shape into form naturally.

Pressing Unit

● Adopt wide belts for pressing, which makes the finished boxes more smooth and better gluing effect.

Trombone Unit

● Slide type adjustment mechanism, flexible and convenient to ensure natural and smooth accumulation of boxes with different sizes in this section. Also it is equipped with electronic sensor count and capacity forecast, sheet kicker and can be automatically tracked.

Conveying Unit

● It is equipped with two independent good quality imported belts that are soft and moderate; Pneumatic pressure design for micro-adjustment of the pressure to ensure perfect pressing effect in this section.
