HR-1450U2
HR-1450U2
Automatic double-sided adhesive applicator
Technical Parameters
| Model: HR-1450U2 | |||
Stickers quantity equipped with machine | 4个 4 pcs | Power frequency | 50/60Hz |
Max.width of double-sided adhesive tape | 80，45，20mm | Power voltage | AC380V |
Max.width of box | 1000mm | Feeding motor power | 0.75kw |
Max.speed of conveyor belt | 80m/min | Alignment motor power | 0.4kw |
Machine weigh | 1045Kg | Applicator motor power | 2.2kw |
Accuracy | ±2mm | Paper delivery motor power | 0.2kw+0.2kw |
Machine floor area | 6600mm×1500mm | Machine total power | 4.5kw |
Application field
Applicable for boxes, delivery bags, corrugated boxes, and smoke/lwine boxes, gift boxes, artwareadhesive.
Structure display
HR-1100C
Automatic double-sided adhesive applicator
Technical specifications
Processing flow diagram
Technical Parameters
| Model: HR-1100C | |||
Stickers quantity equipped with machine | 4 pcs | Power voltage | AC380V |
Max.width of double-sided adhesive tape | 80，45，20mm | Feeding motor power | 1.5KW |
Max.width of box | 1000mm | Main motor power | 3.7KW |
Max.speed of conveyor belt | 80m/min | Collecting motor power | 0.75KW |
Machine floor area | 6600mm×1500mm | Correction motor power | 0.75KW |
Machine weight | 1950Kg | Machine total power | 7KW |
Power frequency | 50/60Hz | ||
Core Business:：
Folding and pasting of color boxes, corrugated boxes, and transparent plastic boxes; platform applications for coding, testing, and special sizing; non-standard automated customization of post-printing processes.
