HR-1050QF/HR-1050QFC
PLC STRIPPING MACHINE
HR-1050QF
Single station high-speed program-controlled waste stripping machine
HR-1050QFC
Double-station high-speed program-controlled waste stripping machine
Technical Parameters
| Model | HR-1050QF | HR-1050QFC |
Hydraulic power | The maximum output power is 3000KG, and the output power range is 1000KG to 3000 KG. | |
Drive | Servo subdivision motor is used to transmit,motion through precision screw ball. | |
Measuring device | Multi direction servo technology, photoelectric device measurement accuracy, sealing design can prevent dirt. | |
Maximum paper size | 1060mm*735mm (Customizable) | |
Minimum paper size | Minimum 300mm*300mm (Customizable) | |
Max. stripping size | 425*425mm (Customizable) | |
Min. stripping size | 30*30mm (Customizable) | |
Piling height | 50-120mm | |
Stripping speed | 1-22mm | |
Max. working pressure(T) | 3.8 | |
Pressure(Pa) | 8 | |
Power | 380V, working 1.5 kilowatts per hour continuously. | |
Weight | 2000kg | 2330kg |
Machine dimension | 2800mm*1850mm*1800mm | 3500*1850*1800mm |
Function Description
● Suitable for automatic stripping of tags/cards, color boxes, transparent plastic boxes, gray boards, special paper and other products.Optional Configuration
● Robatic arm,90°degree rotating collection
Performance and quality
● Longmen's institutional design is more stable than "bird's mouth".
● The machine board is made of national standard steel plate, which can ensure the installation accuracy of linear guide, ball screw, servo motor and other components. Thus, the stability and service life of the equipment used at high frequency are guaranteed, and the maintenance cost is minimized.
● The whole machine adopts the high quality standard parts and electrical components from the world's first-class suppliers to ensure the stability, reliability and operation safety in production.
● The worktable is polished with stainless steel panel, which ensures smooth movement of paper and does not cause scraping. Compared with the electroplating treatment of similar products on the market, there is no need to consider the problem of surface damage and rust.
● HM and PLC computer control, full-color touch screen, so that operators can easily and accurately complete the debugging of the machine and order replacement. The order memory function can store and memorize 160 products.
● Equipped with grating protection to ensure safety in production.
HR-1050QF
Single station high-speed program-controlled waste stripping machine
HR-1050QFC
Double-station high-speed program-controlled waste stripping machine
Device details
High-speed program-controlled waste removal machine
It is an automated waste removal project invested by Herui Automation. After many upgrades, from the initial application to tag and card products, to the wide application of folding color boxes, transparent plastic boxes, and gray boards, special facial tissues and other products in the boutique packaging industry, hundreds of companies have been Domestic and foreign customers provide faster, more efficient, and lower labor intensity waste removal process applications.
Function description
It is suitable for automatic waste removal of tags/cards, color boxes, transparent plastic boxes, gray boards, special facial tissues and other products.
Performance quality
● The gantry mechanism design provides unquestionable stability compared to the "beak type".
● The machine body is finished and assembled with national standard steel plate, which can fully guarantee the installation accuracy of linear guides, ball screws, servo motors and other
components. So as to ensure the stability and service life of the equipment in high frequency use, and minimize the maintenance cost.
● The whole machine uses high-quality standard parts and electrical components from world-class suppliers to ensure the stability and reliability of the waste stripper in production and safe
operation.
Main electrical appliances: Taiwan's Delta, France's Schneider, Japan's Omron.
Key components: Shanghai Bank of Taiwan, AirTAC Taiwan.
● The workbench is made of stainless steel panels with fine grinding treatment to ensure the smooth movement of the paper without scratching. Compared with the electroplating method of
similar products on the market, there is no need to consider the problem of surface damage and rust.
● Man-machine and PLC computer control, full-color touch screen, so that the operator can easily and accurately complete the calibration and order replacement. Order memory function, can
store and memorize 160 products.
● Equipped with grating protection to ensure the safety of personnel production.
Technical indicators of high-speed program-controlled waste stripping machine
| 型号 Model | HR-1050QF | HR-1050QFC |
|
液压功率 Hydraulic power |
最大输出功率3000KG，输出功率范围1000KG至3000 KG The maximum output power is 3000KG, and the output power range is 1000KG to 3000 KG. |
|
| 传动 Drive |
采用伺服细分马达，运动传递通过精密滚珠丝而完成 Servo subdivision motor is used to transmit,motion through precision screw ball. |
|
| 测量装置 Measuring device |
多向随动技术，光电装置的测量精度，密封设计可防尘污 Multi direction servo technology, photoelectric device measurement accuracy, sealing design can prevent dirt. |
|
| 最大纸张幅面 Maximum paper size | 1060mm*735mm（可定制/Customizable) | |
| 最小纸张幅面Minimum paper size | 最小/Minimum 300mm*300mm（可定制/Customizable) | |
| 最大脱标规格Max. stripping size | 425*425mm（可定制/Customizable) | |
| 最小脱标规格Min. stripping size | 50*50mm（可定制/Customizable) | |
| 堆纸高度 Piling height | 50-120mm | |
| 脱标速度Stripping speed | 1-22mm | |
| 最大工作压力（T）Max. working pressure | 3.8 | |
| 气压（pa） Pressure | 8 | |
| 用电功率 Power | 380V，连续工作1.5千瓦／小时 380V, working 1.5 kilowatts per hour continuously. | |
| 重量 Weight | 2000kg | 2330kg |
| 机械尺寸 Machine dimension | 2800mm*1850mm*1800mm | 3500*1850*1800mm |
Core Business:：
Folding and pasting of color boxes, corrugated boxes, and transparent plastic boxes; platform applications for coding, testing, and special sizing; non-standard automated customization of post-printing processes.
